PCB Manufacturing and Assembly
Our Service Portfolio
In collaboration with our trusted manufacturing partners, we deliver a full spectrum of PCB and PCBA production solutions, supporting your project from early design concepts all the way to mass manufacturing.
All services are executed through our jointly qualified facilities, equipped with advanced production lines and strict quality assurance systems to maintain accuracy, consistency, and durability.
PCB Manufacturing
Together with our partner factories, we produce tailor-made printed circuit boards suited for a wide range of applications from simple single-layer designs to intricate multilayer and flexible structures.
High-grade materials, automated fabrication processes, and precise machining ensure stable electrical performance and tight dimensional control.
Key Capabilities:
- Fabrication from 1 to 32 layers
- FR-4, aluminum-based, and flexible board materials
- Copper weight: 1oz to 4oz
- Minimum line/space: 4/4 mil
- Finishes: HASL, ENIG, OSP, immersion silver, gold plating
- Controlled impedance and via filling options
PCBA (Assembly Services)
Our assembly lines, operated jointly with our partner manufacturers, cover the complete PCB assembly process, from SMT placement to THT soldering.
Every assembled board undergoes extensive inspections, including AOI, X-ray, and performance testing, ensuring each unit meets strict quality standards
Assembly Capabilities:
- SMT, THT, and hybrid assembly solutions
- BGA and fine-pitch component placement
- Lead-free and RoHS-approved soldering
- Functional tests, ICT checks, and burn-in procedures
- Protective coatings and board cleaning services
Prototyping & Low-Volume Builds
For rapid development cycles, we offer accelerated fabrication and assembly for prototypes and limited-quantity runs.
These services are ideal for product trials, engineering tests, and early-stage validation, with flexible minimum order quantities
Highlights:
- Fast delivery for prototypes
- Controlled small-batch production with complete traceability
- DFM guidance before moving to large-scale production
Component Procurement & Supply Chain Management
Our engineering and sourcing teams, working closely with our partner network, oversee the entire component procurement process.
We acquire components exclusively through verified, authorized distributors to maintain authenticity and traceability.
Support Provided:
- Thorough BOM evaluation and confirmation
- Cost-effective sourcing and alternative part suggestions
- Inventory coordination and procurement tracking
Testing & Quality Control
Every batch we deliver is validated through rigorous joint testing protocols conducted by both DeltaChip and our certified production partners.
Detailed inspection summaries and test reports are available upon request to support documentation, audits, or compliance requirements.
Testing Options:
- Manual inspection and AOI verification
- In-circuit testing (ICT)
- Full functional load testing
- X-ray analysis for BGAs and ultra-fine components
